MILLER TP-104 4 Color

Miller TP104 Unimatic C3 Perfecting, 4 color printing machine. Mesin cetak 4 warna, cocok utk mesin cetak koran – majalah – tabloid.

MAN Miller TP 104 Unimatic C3 | Mesin cetak koran

Lihat spesifikasi mesin cetak 4 warna MAN Miller TP 104 Unimatic C3


MAN Miller TP 104 Unimatic C3 | 4 Color Printing Machine


MAN Miller TP 104 Unimatic C3 | 4 Color Printing Machine

MAN Miller TP 104 Unimatic C3 | Mesin cetak 4 warna

Miller TP104 Unimatic C3 | Mesin cetak 4 warna
MAN Miller TP 104 Unimatic C3 Perfecting | Mesin cetak koran

Miller TP 104 Unimatic C3 | Mesin cetak koran

Spesification Miller TP 104

  • Miller TP 104 Unimatic C3 | 4 Colors
  • Manufacturer: MAN Miller
  • Year: 1991
  • Max sheet size: 104 x 74 cm
  • Max image area: 103 x 71 cm
  • 4 colors (2+2), with perfector (perfecting)
  • ALCOTRON alcohol dampening system
  • Speed: 13.000 sheets/hour

Full specifications Miller TP 104 from the manufacturer:

  • Maximum Sheet Size 740 x 1040 mm (28 3/8 x 41 inches)
  • Minimum Sheet Size 360 x 520 mm (14 1/4 x 20 1/2 inches)
  • Range Of Stock Thickness .06-.5 mm (.0025-.020 inches)
  • Maximum Image Size Straight Color 710 x 1030 mm (27 15/16 x 40 1/2 inces)
  • Maximum Image Size Perfecting 700 x 1040 mm (27 1/2 x 41 inches)
  • Gripper Margin 10.5-11.5 mm (13/32-7/16 inches)
  • Maximum Plate Size 795 x 1045 mm (31 1/4 x 41 1/8 inches)
  • Edge Of Maximum Plate To Start Print 45 mm (1 3/4 inches)
  • Minimum Plate Size 775 x 1045 mm (30 1/2 x 41 1/8 inches)
  • Edge Of Minimum Plate To Start Print 35 mm (1 3/8 inches)
  • Standard Plate Cylinder Grind 0.5 mm (0.020 inches)
  • Thickness Of Plate With Packing 0.5 mm (0.020 inches)
  • Blanket Size Unquenched (Add 1″ for Punched) 885 x 1060 mm (34 7/8 x 41 3/4 inches)
  • Blanket Cylinder Undercut 2.0 mm (0.079 inches)
  • Blanket Thickness With Packing 2.1 mm (0.083 inches)
  • Maximum Feeder Pile With Pallet 1400 mm (4′ 7″)
  • Maximum Delivery Pile With Pallet 1130 mm (3′ 8 1/2″)

Status: SOLD-OUT, kirim ke TIMIKA – PAPUA


Anda berminat… ?!? ORDER TO : NOVARO


Update….:

Mesin cetak Miller TP 104 ini digunakan sebagai mesin cetak koran pada Harian Pagi Salam Papua ( Koran Salam Papua ) – Timika

Koran Salam Papua - Timika

 Koran Salam Papua – Timika


UPDATE mesin cetak koran :

Mesin cetak koran | Miller TP 94Mesin cetak koran | Miller TP 94

Spesifikasi:

  • Brand : Miller
  • Model : TP 94 – 4C
  • Year : 1990
  • colours : 4 color offset
  • Size: 65 x 94 cm
  • powder sprayer
  • Unimatic Commands Table
  • Alcotronic Dampening
